MIL-DTL-001298D (AR)
TABLE III. M2 caliber .50 heavy machine gun, flexible
Groups of non-mating parts flexible
Group I
Group II
Bar, Trigger
6257592
Bolt Subassembly
6147463
Barrel Assy
7266131
Rod Assy, Oil Buffer Piston
6008763
Extension Assy, Firing Pin
6008976
Pin, Locking
7312970
Extractor Assy
6008959
Spring, Cover Extractor
6009741
Pin, Cocking Lever
7312078
Pawl, Cover Detent
7313069
Spring, Cover Latch
6008931
Pin Assy, Breech Lock
6008784
Cam, Lock Breech
6147583
Pin Assy, Trigger Bar
7313106
Shoulder Bolt
5013681
Spring, Helical Corn
5013693
Slide, Retracting
6147893
Carrier Assy, Barrel
5504080
Spring, Switch
6008943
Nut, Slotted, Hexagon
5013686
Sight Assy, Rear
12003047
Group III
Group IV
Slide, Sear
5351220
Lever, Cocking
6009718
Switch; Bolt
5504062
Sear
5504067
Tube, Barrel Buffer
9340486
Stop, Accelerator
7161301
Pin Assy, Belt Feed Pawl
6008962
Spring, Helical Comp
6009832
Spring, Helical Comp
5013516
Plunger, Belt Feed Lever
5013515
Plunger, Adjusting Screw
5152839
Release, Bolt Latch
5504071
Leaf Assy, Rear Sight
7267936
Lever, Retracting Slide
6147085
Handle Assy, Retracting Slide
6313799
Stop, Front Cartridge
5013539
5013691 or
Spring, Helical Torsion
5013692
Stop Assy, Adjustable Trigger Bar
7265211
Rod, Bolt Latch
6008919
Group V
Group VI
Lock, Accelerator Stop
7161300
Accelerator, Oil Buffer
5508141
Spring, Helical Comp
5009524
Slide Assy, Belt Feed
6261110
Guide Assy, Buffer Spring
6008782
Pin, Shoulder, Headless
5013424
Spring, Helical Comp
5009351
Nut, Slotted Hexagon
5152939
Pawl Assy, Belt Holding
7313083
Screw, Externally Relieved Body
7312028
Sleeve, Buffer Tube
5504094
Retracting Slide Plunger
6008990
Rod Assy, Driving Spring
5564305
Washer, Thrust
5013697
Stop, Rear Cartridge
5013540
Stripper, Link
5013541
Spring, Helical Comp
5013525
Spring, Helical Comp
5013527
Trigger
13016069
Plate Assembly, Back
5564307
with Tube Handle
5009369
& Grip Handle
7265561
& Screw, Handle Tube
5009394
