MIL-DTL-001298D (AR)
TABLE I. Malfunctions and unserviceable components.
Number permitted per,
Malfunctions (attributable to gun) 2/
10,000 rounds
Extruded primer
1
Failure to eject
1
Failure to extract (cartridge case from chamber)
1
Failure to extract (cartridge from feed belt)
1
Failure to feed (bullet striking face of barrel)
2
Failure to feed (insufficient recoil)
1
Hangfire (noticeable)
0
Misfire caused by light blow
2
Pierced primer
1
Uncontrolled fire
0
All other malfunctions:
If correctable by recharging
3
If not correctable by recharging
1
Number permitted per,
Unserviceable components
10,000 rounds 1/
Accelerator
0
Back Plate
0
Barrel extension
0
Barrel support
0
Belt feed pawl
0
Belt feed slide
0
Bolt
0
Breech lock cam
0
Cocking lever
0
Cover pin
0
Driving springs, (inner and outer)
0
Ejector
1
Extractor
0
Extractor cam
0
Firing pin
1
Firing pin spring
0
Sear
1
