MIL-DTL-001298D (AR)
TABLE I. Malfunctions and unserviceable components - Continued
Number permitted per,
Unserviceable components
10,000 rounds 1/
Set back of recoil plate in face of bolt
0
(in excess of .0002 inch)
Side, top, or bottom plates (receiver assembly)
0
All other unserviceable components (different)
2
Notes:
1/ No unserviceable components shall be allowed within the first 5,000
rounds.
2/ When malfunctions (within the allowances of Table I) are traceable to
particular components, it is permissible to replace such components and
record them as unserviceable, subject to limitations of Table I. When it
is definitely established by the inspector that previously recorded
malfunctions are attributable to an unserviceable component, such
malfunctions shall not be counted against the machine gun being tested,
provided that they occurred not more than 200 rounds prior to
replacement of the unserviceable component. However, such
malfunctions shall remain recorded and properly identified.
3.19 UID. A UID label shall be firmly affixed to the receiver assembly. Each M2
shall be identified by a serial number which shall appear on both the top plate of the receiver
assembly and on the UID label. The UID label shall not negatively affect the receiver's
protective finish and must withstand all requirements.
3.20 Hangfires and misfires. If hangfires and misfires occur during any of the tests,
that are not attributed to ammunition, the M2 shall be subjected to the firing pin indent test
per 3.8.
3.21 Workmanship. Workmanship shall be in accordance with the workmanship
requirements of MIL-W-63150. In addition, the M2 shall be free from dust, rust, corrosive
products, and other foreign matter. The cleaning method used shall not be injurious to any
parts nor shall the parts be contaminated by the cleaning agent. All parts shall function
without binding. No parts shall fall of or become loose during any of the firing in this
specification.
